Single Cup Rotary Table Filling & Sealing Machine
Equipment Specifications Table
| Parameter Information | Details | Parameter Information | Details |
|---|---|---|---|
| Product Capacity | 10~15 Cycles/min | Air Pressure | 4~6kg/cm² |
| Machine Power Supply | AC 220V 1200W | Machine Dimensions | 1270*1140*1665mm |
| Sealing Method | Heat Press Sealing | Production Process | Cup dropping → No-cup detection → Filling → Photoelectric eye sealing position correction → Printing → Sealing/Cup lid cutting → Finished product arrangement (one-stop operation) |
| Filling Range | 50-500ml | Notes | Parameters are for reference only; cup types can be customized according to customer-specific requirements |
| Machine Horsepower | 1/4HP | – | – |
Product Introduction
Automated Workflow
Automatic Cup Dropping → Automatic Filling → Automatic Cup Sealing → Automatic Output
Features
- Traditional operation panel: Simple and easy to understand.
- Independent temperature control for sealing molds: Equipped with feedback control.
- Photoelectric eye positioning: Automatically tracks and corrects the sealing position, ensuring precise alignment of film printing.
- Durable construction: Entire machine is made of stainless steel and aluminum alloy, featuring firm stability and rust resistance.
- Precise filling: Accurate quantitative filling, with liquid level control for the hopper and automatic material supply.
Application Effect
